unidbg(2)

参考

Unidbg 的基本使用（二）

hook

frida

进入jadx

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
package com.sina.weibo.security;

import android.util.Base64;
import java.io.ByteArrayOutputStream;
import java.security.Key;
import java.security.KeyFactory;
import java.security.PublicKey;
import java.security.spec.X509EncodedKeySpec;
import javax.crypto.Cipher;

/* loaded from: classes.dex */
public class WeicoSecurityUtils {
    private static final String KEY_ALGORITHM = "RSA";
    private static final String KEY_CIPHER_ALGORITHM = "RSA/ECB/PKCS1Padding";
    private static final int MAX_DECRYPT_BLOCK = 128;
    private static final int MAX_ENCRYPT_BLOCK = 117;
    private static String publicKeyInner = "MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQDWcQcgj60fU8fFev9RlvFPg0GcRgHyGFTN9ytE\nLujvfCwGt7n54Q9+k1rDDo+sRQeYdTwA7ZMS8n1RHjZATgmHw9rBBzk/cHXAVIgrJrZ5txDdW1i4\n8ZxEarcdSrmlk9ZFSsvGXE8/0fZYHM0mr4WaIh2y9E0CNkd0rU9VKAR9RQIDAQAB";
    private static final String publicKeyString = "iMxVDGf9f5Z3P3NsFac7tM7SC6DZDJY+H/vXc+xv3HlT2E/LUzWf5fct2P0VauekLzNAaNsH93SZ\n2Z3jUc/0x81FLThPwI8cexCuRT7P1bdnmcwhjZmW3Lc1FCu2K6iBuVQ9I51TR9eTU2lNcq4AW8WV\nEWtwIj6EpLFzQ3qOm3AY4UNgcGrNYYBbF+SiUkchdXbxYRBNFkguDiayaJzMC/5WmTrEnQ0xXwmy\nA2lWpZ6+sUlyDRU/HvPh5Oto0xpuLc6bIjfl0b+PSjxh5e/7/4jXoYoUfdm3r2FtPKJtQ2NeKnsp\nOCdk6HNULtk5WSnkBKjufQqoZblvdrEiixnogQ";
    String source = KEY_CIPHER_ALGORITHM;

    public static String securityPsd(String password) {
        byte[] data = password.getBytes();
        try {
            String realPublicKeyString = decode(publicKeyString);
            byte[] encodedData = encryptByPublicKey(data, realPublicKeyString);
            return new String(Base64.encode(encodedData, 2));
        } catch (Exception e) {
            e.printStackTrace();
            return null;
        }
    }

    private static byte[] encryptByPublicKey(byte[] data, String publicKey) throws Exception {
        byte[] cache;
        byte[] keyBytes = Base64.decode(publicKey.getBytes(), 2);
        X509EncodedKeySpec x509KeySpec = new X509EncodedKeySpec(keyBytes);
        KeyFactory keyFactory = KeyFactory.getInstance(KEY_ALGORITHM);
        PublicKey publicK = keyFactory.generatePublic(x509KeySpec);
        Cipher cipher = Cipher.getInstance(KEY_CIPHER_ALGORITHM);
        cipher.init(1, publicK);
        int inputLen = data.length;
        ByteArrayOutputStream out = new ByteArrayOutputStream();
        int offSet = 0;
        int i = 0;
        while (inputLen - offSet > 0) {
            if (inputLen - offSet > MAX_ENCRYPT_BLOCK) {
                cache = cipher.doFinal(data, offSet, MAX_ENCRYPT_BLOCK);
            } else {
                cache = cipher.doFinal(data, offSet, inputLen - offSet);
            }
            out.write(cache, 0, cache.length);
            i++;
            offSet = i * MAX_ENCRYPT_BLOCK;
        }
        byte[] encryptedData = out.toByteArray();
        out.close();
        return encryptedData;
    }

    public static String decode(String encryptedStr) throws Exception {
        byte[] decodedData = decryptByPublicKey(Base64.decode(encryptedStr, 1), publicKeyInner);
        return new String(decodedData);
    }

    public static byte[] decryptByPublicKey(byte[] encryptedData, String publicKey) throws Exception {
        byte[] cache;
        byte[] keyBytes = Base64.decode(publicKey, 1);
        X509EncodedKeySpec x509KeySpec = new X509EncodedKeySpec(keyBytes);
        KeyFactory keyFactory = KeyFactory.getInstance(KEY_ALGORITHM);
        Key publicK = keyFactory.generatePublic(x509KeySpec);
        Cipher cipher = Cipher.getInstance(KEY_CIPHER_ALGORITHM);
        cipher.init(2, publicK);
        int inputLen = encryptedData.length;
        ByteArrayOutputStream out = new ByteArrayOutputStream();
        int offSet = 0;
        int i = 0;
        while (inputLen - offSet > 0) {
            if (inputLen - offSet > 128) {
                cache = cipher.doFinal(encryptedData, offSet, 128);
            } else {
                cache = cipher.doFinal(encryptedData, offSet, inputLen - offSet);
            }
            out.write(cache, 0, cache.length);
            i++;
            offSet = i * 128;
        }
        byte[] decryptedData = out.toByteArray();
        out.close();
        return decryptedData;
    }
}

先尝试frida的方法

1
2
3
4
5
6
7
8
9
10
Java.perform(function() {
  let WeiboSecurityUtils = Java.use("com.sina.weibo.security.WeiboSecurityUtils");
  let current_application = Java.use('android.app.ActivityThread').currentApplication();
  let arg1 = current_application.getApplicationContext();
  let arg2 = "hello world";
  let arg3 = "123456";
  let ret = WeiboSecurityUtils.$new().calculateS(arg1, arg2, arg3);
  console.log("ret:"+ret);
})

这里使用的是frida附加进程来进行一个主动调用

1
2
3
4
[AOSP on Oriole::com.weico.international ]-> ret:d74a75bb
ret:d74a75bb


unidbg

先写一个基本的代码框架

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
package com.unidbgtest2;

import com.github.unidbg.AndroidEmulator;
import com.github.unidbg.arm.backend.Unicorn2Factory;
import com.github.unidbg.linux.android.AndroidEmulatorBuilder;
import com.github.unidbg.linux.android.AndroidResolver;
import com.github.unidbg.linux.android.dvm.AbstractJni;
import com.github.unidbg.linux.android.dvm.DalvikModule;
import com.github.unidbg.linux.android.dvm.DvmClass;
import com.github.unidbg.linux.android.dvm.VM;
import com.github.unidbg.memory.Memory;

import java.io.File;

public class WeiBo extends AbstractJni {
    private final AndroidEmulator emulator;
    private final DvmClass WeiboSecurityUtils;
    private final VM vm;

    public WeiBo() {
        emulator = AndroidEmulatorBuilder
                .for32Bit()
                .addBackendFactory(new Unicorn2Factory(true))
                .setProcessName("com.weico.international")
                .build();
        Memory memory = emulator.getMemory();
        memory.setLibraryResolver(new AndroidResolver(23));
        vm = emulator.createDalvikVM(new File("F:\\repwn\\unidbg-master\\unidbg-master\\unidbg-android\\src\\test\\java\\com\\unidbgtest2\\sinaInternational.apk"));
        vm.setJni(this);
        vm.setVerbose(true);
        DalvikModule dm = vm.loadLibrary("utility", true);
        WeiboSecurityUtils = vm.resolveClass("com/sina/weibo/security/WeiboSecurityUtils");
        dm.callJNI_OnLoad(emulator);
    }

    public static void main(String[] args) {
        WeiBo wb = new WeiBo();
    }
}

这里选择32位是以为在lib文件夹里面他就写了一个armeabi

创建虚拟机

1
vm = emulator.createDalvikVM(new File("F:\\repwn\\unidbg-master\\unidbg-master\\unidbg-android\\src\\test\\java\\com\\unidbgtest2\\sinaInternational.apk"));

导入so 获取对应的

两个重载方法

1
2
3
4
5
6
7
//参数一: 动态库或可执行ELF文件
//参数二: 是否必须执行 init_proc、init_array 这些初始化函数
DalvikModule loadLibrary(File elfFile, boolean forceCallInit);

//参数一：动态库或可执行ELF的文件名
//参数二: 是否必须执行 init_proc、init_array 这些初始化函数
DalvikModule loadLibrary(String libname, boolean forceCallInit);
1
2
3
DalvikModule dm = vm.loadLibrary("F:\\repwn\\unidbg-master\\unidbg-master\\unidbg-android\\src\\test\\java\\com\\unidbgtest2\\armeabi\\libutility.so", true);
        WeiboSecurityUtils = vm.resolveClass("com/sina/weibo/security/WeiboSecurityUtils");
        dm.callJNI_OnLoad(emulator);
